Product Description

Fusion pack of 4 landing glass panel is 200mm wide and designed to be installed with fusion handrail and baserail on landings only, and fixed in place with the fusion glass clamp brackets (available separately in chrome or brushed nickel). Part of the Fusion range of glass and oak modern staircase systems and available in a range of options and finishes.

- Fusion landing glass panel
- Toughened polished glass
- BS EN 12150-12000
- Polished edges
- Panel size 6x200x756mm
- 2x 16mm fixing holes
- Hole fixings centres 715.5mm
- NOT Suitable for Rake Stairs
- For use with un-grooved handrail & baserail
- Opening required between handrail and baserail is 836mm
- Pack of 4

Suitable for all domestic & commercial applications.
Solid construction for quality assurance.
One pack of 2 glass brackets are required per glass panel.
Each panel has fixing holes for easy installation.

For elements glass, stairparts and fixings select from the links below


Richard Burbidge
Product Code

Customer Reviews

Fusion Landing Glass Panel for Staircase 200x756mm (Pack of 4)

Item in Stock

Product Code MMGPL4
